FCPF600N65S3R0L دیتاشیت

FCPF600N65S3R0L

مشخصات دیتاشیت

نام دیتاشیت FCPF600N65S3R0L
حجم فایل 68.558 کیلوبایت
نوع فایل pdf
تعداد صفحات 10

مشاهده دیتاشیت FCPF600N65S3R0L

دانلود دیتاشیت

سایر مستندات

FCPF600N65S3R0L 10 pages

مشخصات فنی

  • RoHS: true
  • Type: -
  • Category: Triode/MOS Tube/Transistor/MOSFETs
  • Datasheet: onsemi FCPF600N65S3R0L
  • Power Dissipation (Pd): -
  • Total Gate Charge (Qg@Vgs): -
  • Drain Source Voltage (Vdss): -
  • Input Capacitance (Ciss@Vds): -
  • Continuous Drain Current (Id): -
  • Gate Threshold Voltage (Vgs(th)@Id): -
  • Reverse Transfer Capacitance (Crss@Vds): -
  • Drain Source On Resistance (RDS(on)@Vgs,Id): -
  • Package: TO-220F
  • Manufacturer: onsemi
  • Series: SuperFET® III
  • Packaging: Tube
  • Part Status: Active
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 650V
  • Current - Continuous Drain (Id) @ 25°C: 6A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 600mOhm @ 3A, 10V
  • Vgs(th) (Max) @ Id: 4.5V @ 600µA
  • Gate Charge (Qg) (Max) @ Vgs: 11nC @ 10V
  • Vgs (Max): ±30V
  • Input Capacitance (Ciss) (Max) @ Vds: 465pF @ 400V
  • FET Feature: -
  • Power Dissipation (Max): 24W (Tc)
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Through Hole
  • Supplier Device Package: TO-220F-3
  • Package / Case: TO-220-3 Full Pack
  • Base Part Number: FCPF600
  • detail: N-Channel 650V 6A (Tc) 24W (Tc) Through Hole TO-220F-3
