دیتاشیت NTSB30U100CT-1G

مشخصات دیتاشیت

دانلود دیتاشیت NTSB_NTSJ_NTST30U100CT	NTSB_NTSJ_NTST30U100CT Datasheet

Manufacturer: ON Semiconductor
Series: -
Packaging: Tube
Part Status: Active
Diode Configuration: 1 Pair Common Cathode
Diode Type: Schottky
Voltage - DC Reverse (Vr) (Max): 100V
Current - Average Rectified (Io) (per Diode): 15A
Voltage - Forward (Vf) (Max) @ If: 800mV @ 15A
Speed: Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr: 675µA @ 100V
Operating Temperature - Junction: -40°C ~ 150°C
Mounting Type: Through Hole
Package / Case: TO-262-3 Long Leads, I²Pak, TO-262AA
Supplier Device Package: I2PAK (TO-262)
Base Part Number: NTSB30
detail: Diode Array 1 Pair Common Cathode Schottky 100V 15A Through Hole TO-262-3 Long Leads, I²Pak, TO-262AA
