NCP81234MNTXG دیتاشیت

NCP81234MNTXG

مشخصات دیتاشیت

نام دیتاشیت NCP81234MNTXG
حجم فایل 82.46 کیلوبایت
نوع فایل pdf
تعداد صفحات 20

مشاهده دیتاشیت NCP81234MNTXG

دانلود دیتاشیت

سایر مستندات

NCP81234 19 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/DC-DC Controllers
  • Function: Step-down type
  • Topology: Step-down
  • Datasheet: onsemi NCP81234MNTXG
  • Input Voltage: 0.6V~5V
  • Duty Cycle (Max): -
  • Number of Outputs: 1
  • Switching Frequency: 1.2MHz
  • Operating Temperature: -40°C~+125°C@(TA)
  • Synchronous Rectification: Yes
  • Package: QFN-28-EP(5x5)
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Discontinued at Digi-Key
  • Output Type: PWM Signal
  • Output Configuration: Positive
  • Output Phases: 2
  • Voltage - Supply (Vcc/Vdd): 0.6V ~ 5V
  • Frequency - Switching: 200kHz ~ 1.2MHz
  • Synchronous Rectifier: Yes
  • Clock Sync: -
  • Serial Interfaces: -
  • Control Features: Current Limit, Enable, Frequency Control, Power Good
  • Mounting Type: Surface Mount
  • Package / Case: 28-VFQFN Exposed Pad
  • Supplier Device Package: 28-QFN (5x5)
  • Base Part Number: NCP81234
  • detail: Buck Regulator Positive Output Step-Down DC-DC Controller IC 28-QFN (5x5)
