NCV5701CDR2G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NCV5701CDR2G
|
|
حجم فایل
|
90.104
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
22
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Gate Drive ICs
-
Datasheet:
onsemi NCV5701CDR2G
-
Fall Time:
7.9ns
-
Load Type:
IGBT
-
Rise Time:
9.2ns
-
Supply Voltage:
20V
-
Number of Drivers:
1
-
Driven Configuration:
High Side;Low Side
-
Operating Temperature:
-40°C~+125°C@(Ta)
-
Peak Output Current(sink):
15mA
-
Peak Output Current(source):
20mA
-
Package:
SOP-8
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Active
-
Channel Type:
Single
-
Gate Type:
IGBT
-
Voltage - Supply:
20V
-
Logic Voltage - VIL, VIH:
0.75V, 4.3V
-
Current - Peak Output (Source, Sink):
20mA, 15mA
-
Input Type:
Inverting
-
Rise / Fall Time (Typ):
9.2ns, 7.9ns
-
Mounting Type:
Surface Mount
-
Package / Case:
8-SOIC (0.154", 3.90mm Width)
-
Supplier Device Package:
8-SOIC
-
Base Part Number:
NCV5701
-
detail:
High-Side or Low-Side Gate Driver IC Inverting 8-SOIC
