دیتاشیت RURP15100-F085P
مشخصات دیتاشیت
| نام دیتاشیت |
RURP15100-F085P
|
| حجم فایل |
50.018
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
7
|
مشخصات فنی
-
RoHS:
true
-
Category:
Diodes/Bridge Rectifiers
-
Datasheet:
onsemi RURP15100-F085P
-
Reverse Voltage (Vr):
1kV
-
Operating Temperature:
-55°C~+175°C
-
Forward Voltage (Vf@If):
1.8V@15A
-
Reverse Leakage Current (Ir):
100uA@1000V
-
Average Rectified Current (Io):
15A
-
Package:
TO-220-2
-
Manufacturer:
onsemi
-
Series:
Automotive, AEC-Q101
-
Packaging:
Tube
-
Part Status:
Active
-
Diode Type:
Standard
-
Voltage - DC Reverse (Vr) (Max):
1000V
-
Current - Average Rectified (Io):
15A
-
Voltage - Forward (Vf) (Max) @ If:
1.8V @ 15A
-
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
-
Reverse Recovery Time (trr):
260ns
-
Current - Reverse Leakage @ Vr:
100µA @ 1000V
-
Capacitance @ Vr, F:
-
-
Mounting Type:
Through Hole
-
Package / Case:
TO-220-2
-
Supplier Device Package:
TO-220-2
-
Operating Temperature - Junction:
-55°C ~ 175°C
-
Base Part Number:
RURP15
-
detail:
Diode Standard 1000V 15A Through Hole TO-220-2
