دیتاشیت MBRB30H30CT-1G
مشخصات دیتاشیت
| نام دیتاشیت | MBR(B)30H30CT(-1)G, NRVBB30H30CT-1G |
|---|---|
| حجم فایل | 98.393 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 7 |
دانلود دیتاشیت MBR(B)30H30CT(-1)G, NRVBB30H30CT-1G |
MBR(B)30H30CT(-1)G, NRVBB30H30CT-1G Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Diodes/Schottky Barrier Diodes (SBD)
- Datasheet: onsemi MBRB30H30CT-1G
- Diode Configuration: Dual Common Cathode
- Reverse Voltage (Vr): 30V
- Forward Voltage (Vf@If): 550mV@30A
- Reverse Leakage Current (Ir): 800uA@30V
- Average Rectified Current (Io): 15A
- Package: TO-262
- Manufacturer: onsemi
- Series: SWITCHMODE™
- Packaging: Tube
- Part Status: Active
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 30V
- Current - Average Rectified (Io) (per Diode): 15A
- Voltage - Forward (Vf) (Max) @ If: 480mV @ 15A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Current - Reverse Leakage @ Vr: 800µA @ 30V
- Operating Temperature - Junction: -55°C ~ 150°C
- Mounting Type: Through Hole
- Package / Case: TO-262-3 Long Leads, I²Pak, TO-262AA
- Supplier Device Package: I2PAK (TO-262)
- Base Part Number: MBRB30
- detail: Diode Array 1 Pair Common Cathode Schottky 30V 15A Through Hole TO-262-3 Long Leads, I²Pak, TO-262AA
