LB1868M-TLM-H Datasheet
Datasheet specifications
| Datasheet's name | LB1868M-TLM-H |
|---|---|
| File size | 73.005 KB |
| File type | |
| Number of pages | 8 |
Download Datasheet LB1868M-TLM-H |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- RoHS: true
- Category: Power Supply Chip/Motor Driver ICs
- Datasheet: onsemi LB1868M-TLM-H
- Interface: -
- Supply Voltage: 6.4V~7V
- Operating Temperature: -30°C~+80°C@(Ta)
- Package: MFP-14S
- Manufacturer: onsemi
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Output Configuration: Half Bridge (2)
- Applications: DC Motors, General Purpose
- Load Type: Inductive
- Technology: Bipolar
- Rds On (Typ): -
- Current - Output / Channel: 1A
- Current - Peak Output: -
- Voltage - Supply: 6.4V ~ 7V
- Voltage - Load: 12V, 24V
- Features: -
- Fault Protection: Over Temperature
- Mounting Type: Surface Mount
- Package / Case: 14-LSOP (0.173", 4.40mm Width)
- Supplier Device Package: 14-MFPS
- Base Part Number: LB1868
- detail: Half Bridge (2) Driver DC Motors, General Purpose Bipolar 14-MFPS
