FDMA037N08LC دیتاشیت

FDMA037N08LC

مشخصات دیتاشیت

نام دیتاشیت FDMA037N08LC
حجم فایل 60.659 کیلوبایت
نوع فایل pdf
تعداد صفحات 8

مشاهده دیتاشیت FDMA037N08LC

دانلود دیتاشیت

سایر مستندات

FDMA037N08LC 8 pages

مشخصات فنی

  • RoHS: true
  • Category: Triode/MOS Tube/Transistor/MOSFETs
  • Datasheet: onsemi FDMA037N08LC
  • Operating Temperature: -55°C~+150°C@(Tj)
  • Power Dissipation (Pd): 2.4W
  • Total Gate Charge (Qg@Vgs): 9nC@10V
  • Drain Source Voltage (Vdss): 80V
  • Input Capacitance (Ciss@Vds): 595pF@40V
  • Continuous Drain Current (Id): 6A
  • Gate Threshold Voltage (Vgs(th)@Id): 2.5V@20uA
  • Drain Source On Resistance (RDS(on)@Vgs,Id): 36.5mΩ@4A,10V
  • Package: WDFN-6
  • Manufacturer: onsemi
  • Series: PowerTrench®
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 80V
  • Current - Continuous Drain (Id) @ 25°C: 6A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
  • Rds On (Max) @ Id, Vgs: 36.5mOhm @ 4A, 10V
  • Vgs(th) (Max) @ Id: 2.5V @ 20µA
  • Gate Charge (Qg) (Max) @ Vgs: 9nC @ 10V
  • Vgs (Max): ±20V
  • Input Capacitance (Ciss) (Max) @ Vds: 595pF @ 40V
  • FET Feature: -
  • Power Dissipation (Max): 2.4W (Ta)
  • Mounting Type: Surface Mount
  • Supplier Device Package: 6-WDFN (2x2)
  • Package / Case: 6-WDFN Exposed Pad
  • Base Part Number: FDMA03
  • detail: N-Channel 80V 6A (Tc) 2.4W (Ta) Surface Mount 6-WDFN (2x2)
