NCV4299CD133R2G دیتاشیت

NCV4299CD133R2G

مشخصات دیتاشیت

نام دیتاشیت NCV4299CD133R2G
حجم فایل 76.992 کیلوبایت
نوع فایل pdf
تعداد صفحات 24

مشاهده دیتاشیت NCV4299CD133R2G

دانلود دیتاشیت

سایر مستندات

NCV4299C 19 pages

مشخصات فنی

  • RoHS: true
  • Feature: Overcurrent Protection;Thermal Protection
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: onsemi NCV4299CD133R2G
  • Output Current: 150mA
  • Output Voltage: 3.3V
  • Output Polarity: positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 45V
  • Operating Temperature: -40°C~+150°C
  • Quiescent Current (Ground Current): 90uA
  • Power Supply Rejection Ratio (PSRR): 66dB@(100Hz)
  • Package: SOP-8
  • Manufacturer: onsemi
  • Series: Automotive, AEC-Q100
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Output Configuration: Positive
  • Output Type: Fixed
  • Number of Regulators: 1
  • Voltage - Input (Max): 45V
  • Voltage - Output (Min/Fixed): 3.3V
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): -
  • Current - Output: 150mA
  • Current - Quiescent (Iq): 90µA
  • Current - Supply (Max): 2mA
  • PSRR: 66dB (100Hz)
  • Control Features: Reset
  • Protection Features: Over Current, Over Temperature
  • Mounting Type: Surface Mount
  • Package / Case: 8-SOIC (0.154", 3.90mm Width)
  • Supplier Device Package: 8-SOIC
  • Base Part Number: NCV4299
  • detail: Linear Voltage Regulator IC 1 Output 150mA 8-SOIC
