NCV8518C دیتاشیت

NCV8518C

مشخصات دیتاشیت

نام دیتاشیت NCV8518C
حجم فایل 203.113 کیلوبایت
نوع فایل pdf
تعداد صفحات 15

مشاهده دیتاشیت NCV8518C

دانلود دیتاشیت

سایر مستندات

NCV8518CPDR2G 16 pages

مشخصات فنی

  • RoHS: true
  • Feature: Overcurrent Protection;Thermal Protection
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: onsemi NCV8518CPDR2G
  • Output Current: 250mA
  • Output Voltage: 5V
  • Dropout Voltage: 0.75V@(150mA)
  • Output Polarity: positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 40V
  • Operating Temperature: -40°C~+150°C@(Tj)
  • Quiescent Current (Ground Current): 85uA
  • Package: SOP-8-EP
  • Manufacturer: onsemi
  • Series: Automotive, AEC-Q100
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Output Configuration: Positive
  • Output Type: Fixed
  • Number of Regulators: 1
  • Voltage - Input (Max): 40V
  • Voltage - Output (Min/Fixed): 5V
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): 0.75V @ 150mA
  • Current - Output: 250mA
  • Current - Quiescent (Iq): 85µA
  • PSRR: -
  • Control Features: Enable, Reset, Wake-Up, Watchdog
  • Protection Features: Over Current, Over Temperature, Short Circuit
  • Mounting Type: Surface Mount
  • Package / Case: 8-SOIC (0.154", 3.90mm Width) Exposed Pad
  • Supplier Device Package: 8-SOIC-EP
  • Base Part Number: NCV8518
  • detail: Linear Voltage Regulator IC 1 Output 250mA 8-SOIC-EP
