NTD5C668NLT4G دیتاشیت

NTD5C668NLT4G

مشخصات دیتاشیت

نام دیتاشیت NTD5C668NLT4G
حجم فایل 86.384 کیلوبایت
نوع فایل pdf
تعداد صفحات 8

مشاهده دیتاشیت NTD5C668NLT4G

دانلود دیتاشیت

سایر مستندات

NTD5C668NL 8 pages

مشخصات فنی

  • RoHS: true
  • Category: Triode/MOS Tube/Transistor/MOSFETs
  • Datasheet: onsemi NTD5C668NLT4G
  • Operating Temperature: -55°C~+175°C@(Tj)
  • Power Dissipation (Pd): -
  • Total Gate Charge (Qg@Vgs): -
  • Drain Source Voltage (Vdss): -
  • Input Capacitance (Ciss@Vds): -
  • Continuous Drain Current (Id): 15A;48A
  • Gate Threshold Voltage (Vgs(th)@Id): 2.1V@250uA
  • Reverse Transfer Capacitance (Crss@Vds): -
  • Drain Source On Resistance (RDS(on)@Vgs,Id): 8.9mΩ@25A,10V
  • Package: TO-252
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • FET Type: N-Channel
  • Current - Continuous Drain (Id) @ 25°C: 15A (Ta), 48A (Tc)
  • Rds On (Max) @ Id, Vgs: 8.9mOhm @ 25A, 10V
  • Vgs(th) (Max) @ Id: 2.1V @ 250µA
  • FET Feature: -
  • Mounting Type: Surface Mount
  • Supplier Device Package: DPAK (SINGLE GAUGE)
  • Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
  • Base Part Number: NTD5C
  • detail: N-Channel 15A (Ta), 48A (Tc) Surface Mount DPAK (SINGLE GAUGE)
