FDPC8014AS دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت FDPC8014AS	دانلود دیتاشیت

RoHS: true
Type: 2 N-Channel
Category: Triode/MOS Tube/Transistor/MOSFETs
Datasheet: onsemi FDPC8014AS
Operating Temperature: -55°C~+150°C@(Tj)
Power Dissipation (Pd): 37W
Total Gate Charge (Qg@Vgs): 11nC@4.5V;44nC@4.5V
Drain Source Voltage (Vdss): 25V
Input Capacitance (Ciss@Vds): 1.695nF@13V;6.985nF@13V
Continuous Drain Current (Id): 159A
Gate Threshold Voltage (Vgs(th)@Id): 2.5V@250uA;3V@250uA
Reverse Transfer Capacitance (Crss@Vds): 54pF@13V;172pF@13V
Drain Source On Resistance (RDS(on)@Vgs,Id): 2.9mΩ@10V,20A;0.75mΩ@10V,40A
Package: PQFN-8-EP(5x6)
Manufacturer: onsemi
Series: PowerTrench®
Packaging: Cut Tape (CT)
Part Status: Discontinued at Digi-Key
FET Type: 2 N-Channel (Dual) Asymmetrical
FET Feature: Standard
Drain to Source Voltage (Vdss): 25V
Current - Continuous Drain (Id) @ 25°C: 20A, 40A
Rds On (Max) @ Id, Vgs: 3.8mOhm @ 20A, 10V
Vgs(th) (Max) @ Id: 2.5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs: 35nC @ 10V
Input Capacitance (Ciss) (Max) @ Vds: 2375pF @ 13V
Power - Max: 2.1W, 2.3W
Mounting Type: Surface Mount
Package / Case: 8-PowerWDFN
Supplier Device Package: Power Clip 56
Base Part Number: FDPC8
detail: Mosfet Array 2 N-Channel (Dual) Asymmetrical 25V 20A, 40A 2.1W, 2.3W Surface Mount Power Clip 56
