NCP302155MNTWG دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NCP302155
|
|
حجم فایل
|
801.736
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
18
|
مشخصات فنی
-
Manufacturer:
ON Semiconductor
-
Series:
-
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Active
-
Driven Configuration:
High-Side or Low-Side
-
Channel Type:
Single
-
Number of Drivers:
2
-
Gate Type:
N-Channel MOSFET
-
Voltage - Supply:
4.5V ~ 5.5V
-
Logic Voltage - VIL, VIH:
0.7V, 2.65V
-
Current - Peak Output (Source, Sink):
2A, 2.5A
-
Input Type:
Non-Inverting
-
High Side Voltage - Max (Bootstrap):
35V
-
Rise / Fall Time (Typ):
12ns, 6ns
-
Operating Temperature:
-40°C ~ 125°C (TJ)
-
Mounting Type:
Surface Mount
-
Package / Case:
31-PowerWFQFN
-
Supplier Device Package:
31-PQFN (5x5)
-
Base Part Number:
NCP302
-
detail:
High-Side or Low-Side Gate Driver IC Non-Inverting 31-PQFN (5x5)
