DFB2505 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
DFB2505
|
|
حجم فایل
|
49.548
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
5
|
مشخصات فنی
-
RoHS:
true
-
Category:
Diodes/Bridge Rectifiers
-
Datasheet:
onsemi DFB2505
-
Reverse Voltage (Vr):
50V
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Forward Voltage (Vf@If):
1.1V@25A
-
Peak Forward Surge Current:
350A
-
Reverse Leakage Current (Ir):
10uA@50V
-
Average Rectified Current (Io):
25A
-
Package:
TS-6P 4L
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Active
-
Diode Type:
Single Phase
-
Technology:
Standard
-
Voltage - Peak Reverse (Max):
50V
-
Current - Average Rectified (Io):
25A
-
Voltage - Forward (Vf) (Max) @ If:
1.1V @ 25A
-
Current - Reverse Leakage @ Vr:
10µA @ 50V
-
Mounting Type:
Through Hole
-
Package / Case:
4-SIP, TS-6P
-
Supplier Device Package:
TS-6P
-
Base Part Number:
DFB25
-
detail:
Bridge Rectifier Single Phase Standard 50V Through Hole TS-6P
