FDMS001N025DSD دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت FDMS001N025DSD	دانلود دیتاشیت

مستندات دیگری یافت نشد!

Manufacturer: ON Semiconductor
Series: PowerTrench®
Packaging: Tape & Reel (TR)
Part Status: Active
FET Type: 2 N-Channel (Dual) Asymmetrical
FET Feature: Standard
Drain to Source Voltage (Vdss): 25V
Current - Continuous Drain (Id) @ 25°C: 19A (Ta), 69A (Tc), 38A (Ta), 165A (Tc)
Rds On (Max) @ Id, Vgs: 3.25mOhm @ 19A, 10V, 920µOhm @ 38A, 10V
Vgs(th) (Max) @ Id: 2.5V @ 320µA, 3V @ 1mA
Gate Charge (Qg) (Max) @ Vgs: 30nC, 104nC @ 10V
Input Capacitance (Ciss) (Max) @ Vds: 1370pF, 5105pF @ 13V
Power - Max: 2.1W (Ta), 26W (Tc), 2.3W (Ta), 42W (Tc)
Operating Temperature: -55°C ~ 150°C (TJ)
Mounting Type: Surface Mount
Package / Case: 8-PowerWDFN
Supplier Device Package: 8-PQFN (5x6)
Base Part Number: FDMS00
detail: Mosfet Array 2 N-Channel (Dual) Asymmetrical 25V 19A (Ta), 69A (Tc), 38A (Ta), 165A (Tc) 2.1W (Ta), 26W (Tc), 2.3W (Ta), 42W (Tc) Surface Mount 8-PQFN (5x6)
