دیتاشیت NCV4275ADS50R4G-IR01
مشخصات دیتاشیت
| نام دیتاشیت | NCV4275A |
|---|---|
| حجم فایل | 123.184 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 19 |
دانلود دیتاشیت NCV4275A |
NCV4275A Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: onsemi NCV4275ADS50R4G-IR01
- Output Current: 450mA
- Output Voltage: 5V
- Dropout Voltage: 0.5V@(300mA)
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 42V
- Operating Temperature: -40°C~+150°C@(Tj)
- Quiescent Current (Ground Current): 200uA
- Power Supply Rejection Ratio (PSRR): 60dB@(100Hz)
- Package: D2PAK-5
- Manufacturer: onsemi
- Series: Automotive, AEC-Q100
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Output Configuration: Positive
- Output Type: Fixed
- Number of Regulators: 1
- Voltage - Input (Max): 42V
- Voltage - Output (Min/Fixed): 5V
- Voltage - Output (Max): -
- Voltage Dropout (Max): 0.5V @ 300mA
- Current - Output: 450mA
- Current - Quiescent (Iq): 200µA
- Current - Supply (Max): 35mA
- PSRR: 60dB (100Hz)
- Control Features: Reset
- Protection Features: Over Temperature, Reverse Polarity, Short Circuit
- Mounting Type: Surface Mount
- Package / Case: TO-263-6, D²Pak (5 Leads + Tab), TO-263BA
- Supplier Device Package: D2PAK-5
- Base Part Number: NCV4275
- detail: Linear Voltage Regulator IC 1 Output 450mA D2PAK-5
