دیتاشیت LV5749NV-TLM-E
مشخصات دیتاشیت
| نام دیتاشیت |
LV5749NV
|
| حجم فایل |
106.95
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
6
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Controllers
-
Function:
Step-down type
-
Topology:
Step-down
-
Datasheet:
onsemi LV5749NV-TLM-E
-
Input Voltage:
8.5V~42V
-
Duty Cycle (Max):
85%
-
Number of Outputs:
1
-
Switching Frequency:
125kHz
-
Operating Temperature:
-40°C~+85°C@(Ta)
-
Synchronous Rectification:
-
-
Package:
SSOP-16-4.4mm
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Active
-
Output Type:
Transistor Driver
-
Output Configuration:
Positive
-
Output Phases:
1
-
Voltage - Supply (Vcc/Vdd):
8V ~ 42V
-
Frequency - Switching:
125kHz
-
Synchronous Rectifier:
Yes
-
Clock Sync:
Yes
-
Serial Interfaces:
-
-
Control Features:
Current Limit, Enable, Frequency Control, Soft Start
-
Mounting Type:
Surface Mount
-
Package / Case:
16-LSSOP (0.173", 4.40mm Width)
-
Supplier Device Package:
16-SSOP
-
Base Part Number:
LV574
-
detail:
Buck Regulator Positive Output Step-Down DC-DC Controller IC 16-SSOP
