NCV51511 دیتاشیت

NCV51511

مشخصات دیتاشیت

نام دیتاشیت NCV51511
حجم فایل 493.787 کیلوبایت
نوع فایل pdf
تعداد صفحات 14

مشاهده دیتاشیت NCV51511

دانلود دیتاشیت

سایر مستندات

NCV51511PDR2G 17 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Gate Drive ICs
  • Datasheet: onsemi NCV51511PDR2G
  • Package: VFQFN-24
  • Manufacturer: onsemi
  • Series: Automotive, AEC-Q100
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Driven Configuration: High-Side or Low-Side
  • Channel Type: Synchronous
  • Number of Drivers: 2
  • Gate Type: N-Channel MOSFET
  • Voltage - Supply: 8V ~ 16V
  • Logic Voltage - VIL, VIH: 2V, 1.8V
  • Current - Peak Output (Source, Sink): 3A, 6A
  • Input Type: Non-Inverting
  • High Side Voltage - Max (Bootstrap): 100V
  • Rise / Fall Time (Typ): 6ns, 4ns
  • Operating Temperature: -40°C ~ 150°C (TJ)
  • Mounting Type: Surface Mount
  • Package / Case: 8-SOIC (0.154", 3.90mm Width) Exposed Pad
  • Supplier Device Package: 8-SOIC-EP
  • Base Part Number: NCV51511
  • detail: High-Side or Low-Side Gate Driver IC Non-Inverting 8-SOIC-EP
