دیتاشیت FGI3040G2-F085

FGx3040G2-F085

مشخصات دیتاشیت

نام دیتاشیت FGx3040G2-F085
حجم فایل 1633.649 کیلوبایت
نوع فایل pdf
تعداد صفحات 9

دانلود دیتاشیت FGx3040G2-F085

FGx3040G2-F085 Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: Automotive, AEC-Q101, EcoSPARK®
  • Packaging: Tube
  • Part Status: Active
  • IGBT Type: -
  • Voltage - Collector Emitter Breakdown (Max): 400V
  • Current - Collector (Ic) (Max): 41A
  • Vce(on) (Max) @ Vge, Ic: 1.25V @ 4V, 6A
  • Power - Max: 150W
  • Switching Energy: -
  • Input Type: Logic
  • Gate Charge: 21nC
  • Td (on/off) @ 25°C: 900ns/4.8µs
  • Test Condition: -
  • Operating Temperature: -55°C ~ 175°C (TJ)
  • Mounting Type: Through Hole
  • Package / Case: TO-262-3 Long Leads, I²Pak, TO-262AA
  • Supplier Device Package: I2PAK (TO-262)
  • Base Part Number: FGI3
  • detail: IGBT 400V 41A 150W Through Hole I2PAK (TO-262)
