دیتاشیت FDBL86363-F085

FDBL86363-F085

مشخصات دیتاشیت

نام دیتاشیت FDBL86363-F085
حجم فایل 497.213 کیلوبایت
نوع فایل pdf
تعداد صفحات 7

دانلود دیتاشیت FDBL86363-F085

FDBL86363-F085 Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: Automotive, AEC-Q101, PowerTrench®
  • Packaging: Cut Tape (CT)
  • Part Status: Discontinued at Digi-Key
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 80V
  • Current - Continuous Drain (Id) @ 25°C: 240A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 2mOhm @ 80A, 10V
  • Vgs(th) (Max) @ Id: 4V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs: 169nC @ 10V
  • Vgs (Max): ±20V
  • Input Capacitance (Ciss) (Max) @ Vds: 10000pF @ 40V
  • FET Feature: -
  • Power Dissipation (Max): 357W (Tj)
  • Operating Temperature: -55°C ~ 175°C (TJ)
  • Mounting Type: Surface Mount
  • Supplier Device Package: 8-HPSOF
  • Package / Case: 8-PowerSFN
  • Base Part Number: FDBL863
  • detail: N-Channel 80V 240A (Tc) 357W (Tj) Surface Mount 8-HPSOF
