FOD3125 دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت FOD3125	دانلود دیتاشیت

RoHS: true
Category: Optocoupler/LED/Digital Tube/Photoelectric Device/Optocouplers - Logic Output
Datasheet: onsemi FOD3125SD
Input Type: DC
Supply Voltage: 15V~30V
Number of Channels: 1
Operating Temperature: -40°C~+125°C
Isolation Voltage(rms): 5000V
Propagation Delay tpLH/tpHL: 400ns
Common Mode Transient Immunity (CMTI): 35 kV/us
Package: SOP-8-2.54mm
Manufacturer: onsemi
Series: OPTOPLANAR®
Part Status: Active
Technology: Optical Coupling
Voltage - Isolation: 5000Vrms
Common Mode Transient Immunity (Min): 35kV/µs
Propagation Delay tpLH / tpHL (Max): 400ns, 400ns
Pulse Width Distortion (Max): 100ns
Rise / Fall Time (Typ): 60ns, 60ns
Current - Output High, Low: 2A, 2A
Current - Peak Output: 3A
Voltage - Forward (Vf) (Typ): 1.5V
Current - DC Forward (If) (Max): 25mA
Voltage - Output Supply: 15V ~ 30V
Mounting Type: Surface Mount
Package / Case: 8-SMD, Gull Wing
Supplier Device Package: 8-SMD
Approval Agency: UL
Base Part Number: FOD312
detail: 3A Gate Driver Optical Coupling 5000Vrms 1 Channel 8-SMD
