NCP1566MNTXG دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NCP1566MNTXG
|
|
حجم فایل
|
93.239
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
38
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/AC-DC Controllers & Regulators
-
Topology:
Forward
-
Datasheet:
onsemi NCP1566MNTXG
-
Duty Cycle:
80.5%
-
Supply Voltage:
6.5V~120V
-
Switching Frequency:
100kHz~1MHz
-
Operating Temperature:
-40°C~+150°C@(TJ)
-
Package:
QFN-24-EP(4x4)
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Active
-
Output Type:
Transistor Driver
-
Function:
Step-Up/Step-Down
-
Output Configuration:
Positive, Isolation Capable
-
Number of Outputs:
2
-
Output Phases:
1
-
Voltage - Supply (Vcc/Vdd):
6.5V ~ 120V
-
Frequency - Switching:
100kHz ~ 1MHz
-
Duty Cycle (Max):
80.5%
-
Synchronous Rectifier:
Yes
-
Clock Sync:
Yes
-
Serial Interfaces:
-
-
Control Features:
Current Limit, Dead Time Control, Enable, Frequency Control, Ramp, Soft Start, Sync
-
Package / Case:
24-VFQFN Exposed Pad
-
Supplier Device Package:
24-QFN (4x4)
-
Base Part Number:
NCP1566
-
detail:
Forward Converter Regulator Positive, Isolation Capable Output Step-Up/Step-Down DC-DC Controller IC 24-QFN (4x4)
