FGB3040CS دیتاشیت

FGB3040CS

مشخصات دیتاشیت

نام دیتاشیت FGB3040CS
حجم فایل 85.524 کیلوبایت
نوع فایل pdf
تعداد صفحات 9

مشاهده دیتاشیت FGB3040CS

دانلود دیتاشیت

سایر مستندات

FGB3040CS 9 pages

مشخصات فنی

  • RoHS: true
  • Type: -
  • Category: Triode/MOS Tube/Transistor/IGBTs
  • Datasheet: onsemi FGB3040CS
  • Operating Temperature: 40°C~+175°C@(Tj)
  • Collector Current (Ic): 21A
  • Power Dissipation (Pd): 150W
  • Input Capacitance (Cies@Vce): -
  • Turn?on Switching Loss (Eon): -
  • Total Gate Charge (Qg@Ic,Vge): 15nC
  • Turn?off Delay Time (Td(off)): 4.7us
  • Collector-Emitter Breakdown Voltage (Vces): 430V
  • Gate-Emitter Threshold Voltage (Vge(th)@Ic): 1.6V@4V,6A
  • Package: TO-263-6
  • Manufacturer: onsemi
  • Series: EcoSPARK®
  • Packaging: Cut Tape (CT)
  • Part Status: Discontinued at Digi-Key
  • IGBT Type: -
  • Voltage - Collector Emitter Breakdown (Max): 430V
  • Current - Collector (Ic) (Max): 21A
  • Vce(on) (Max) @ Vge, Ic: 1.6V @ 4V, 6A
  • Power - Max: 150W
  • Switching Energy: -
  • Input Type: Logic
  • Gate Charge: 15nC
  • Td (on/off) @ 25°C: -/4.7µs
  • Test Condition: 300V, 1kOhm, 5V
  • Mounting Type: Surface Mount
  • Package / Case: TO-263-7, D²Pak (6 Leads + Tab), TO-263CB
  • Supplier Device Package: TO-263-6
  • Base Part Number: FGB3
  • detail: IGBT 430V 21A 150W Surface Mount TO-263-6
