دیتاشیت FDBL86063-F085
مشخصات دیتاشیت
| نام دیتاشیت |
FDBL86063-F085
|
| حجم فایل |
700.659
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
6
|
مشخصات
-
Manufacturer:
ON Semiconductor
-
Series:
PowerTrench®
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Active
-
FET Type:
N-Channel
-
Technology:
MOSFET (Metal Oxide)
-
Drain to Source Voltage (Vdss):
100V
-
Current - Continuous Drain (Id) @ 25°C:
240A (Tc)
-
Drive Voltage (Max Rds On, Min Rds On):
10V
-
Rds On (Max) @ Id, Vgs:
2.6mOhm @ 80A, 10V
-
Vgs(th) (Max) @ Id:
4V @ 250µA
-
Gate Charge (Qg) (Max) @ Vgs:
95nC @ 10V
-
Vgs (Max):
±20V
-
Input Capacitance (Ciss) (Max) @ Vds:
5120pF @ 50V
-
FET Feature:
-
-
Power Dissipation (Max):
357W (Tj)
-
Operating Temperature:
-55°C ~ 175°C (TJ)
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
8-HPSOF
-
Package / Case:
8-PowerSFN
-
Base Part Number:
FDBL860
-
detail:
N-Channel 100V 240A (Tc) 357W (Tj) Surface Mount 8-HPSOF
