دیتاشیت FQH44N10-F133

FQH44N10_F133

مشخصات دیتاشیت

نام دیتاشیت FQH44N10_F133
حجم فایل 416.032 کیلوبایت
نوع فایل pdf
تعداد صفحات 9

دانلود دیتاشیت FQH44N10_F133

FQH44N10_F133 Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: QFET®
  • Packaging: Tube
  • Part Status: Active
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 100V
  • Current - Continuous Drain (Id) @ 25°C: 48A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 39mOhm @ 24A, 10V
  • Vgs(th) (Max) @ Id: 4V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs: 62nC @ 10V
  • Vgs (Max): ±25V
  • Input Capacitance (Ciss) (Max) @ Vds: 1800pF @ 25V
  • FET Feature: -
  • Power Dissipation (Max): 180W (Tc)
  • Operating Temperature: -55°C ~ 175°C (TJ)
  • Mounting Type: Through Hole
  • Supplier Device Package: TO-247-3
  • Package / Case: TO-247-3
  • Base Part Number: FQH4
  • detail: N-Channel 100V 48A (Tc) 180W (Tc) Through Hole TO-247-3
