FOD8012R2 دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت FOD8012R2	دانلود دیتاشیت

مستندات دیگری یافت نشد!

RoHS: true
Category: Optocoupler/LED/Digital Tube/Photoelectric Device/Optocouplers - Logic Output
Data Rate: 15Mbit/s
Datasheet: onsemi FOD8012R2
Input Type: High Speed
Supply Voltage: 3V~3.6V;4.5V~5.5V
Number of Channels: 2
Operating Temperature: -40°C~+110°C
Isolation Voltage(rms): 3750V
Propagation Delay tpLH/tpHL: 60ns
Common Mode Transient Immunity (CMTI): 20kV/us
Package: SOP-8
Manufacturer: onsemi
Series: -
Packaging: Cut Tape (CT)
Part Status: Discontinued at Digi-Key
Inputs - Side 1/Side 2: 1/1
Voltage - Isolation: 3750Vrms
Common Mode Transient Immunity (Min): 20kV/µs
Output Type: Push-Pull, Totem Pole
Current - Output / Channel: 10mA
Propagation Delay tpLH / tpHL (Max): 60ns, 60ns
Rise / Fall Time (Typ): 6.5ns, 6.5ns
Voltage - Forward (Vf) (Typ): -
Current - DC Forward (If) (Max): -
Voltage - Supply: 3V ~ 3.6V, 4.5V ~ 5.5V
Mounting Type: Surface Mount
Package / Case: 8-SOIC (0.154", 3.90mm Width)
Supplier Device Package: 8-SOIC
Base Part Number: FOD801
detail: Logic Output Optoisolator 15Mbps Push-Pull, Totem Pole 3750Vrms 2 Channel 20kV/µs CMTI 8-SOIC
