FAN2103MPX دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت FAN2103MPX	دانلود دیتاشیت

FAN2103 15 pages

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: Step-down type
Topology: Step-down
Datasheet: onsemi FAN2103MPX
Output Type: Adjustable
Input Voltage: 3V~24V
Output Voltage: 0.8V~21.6V
Number of Outputs: 1
Switching Frequency: 600kHz
Output Current (Max): 3A
Operating Temperature: -10°C~+85°C@(TA)
Synchronous Rectification: Yes
Package: MLP-25
Manufacturer: onsemi
Series: TinyBuck®
Packaging: Cut Tape (CT)
Part Status: Discontinued at Digi-Key
Output Configuration: Positive
Voltage - Input (Min): 3V
Voltage - Input (Max): 24V
Voltage - Output (Min/Fixed): 0.8V
Voltage - Output (Max): 21.6V
Current - Output: 3A
Frequency - Switching: 300kHz ~ 600kHz
Synchronous Rectifier: Yes
Mounting Type: Surface Mount
Package / Case: 25-WQFN Exposed Pad
Supplier Device Package: 25-MLP (6x5)
Base Part Number: FAN2103
detail: Buck Switching Regulator IC Positive Adjustable 0.8V 1 Output 3A 25-WQFN Exposed Pad
