NCV2575D2T-5R4G Datasheet
Datasheet specifications
| Datasheet's name | NCV2575D2T-5R4G |
|---|---|
| File size | 100.619 KB |
| File type | |
| Number of pages | 29 |
Download Datasheet NCV2575D2T-5R4G |
Download Datasheet |
|---|
Other documentations
LM2575 28 pages
Technical specifications
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: Step-down type
- Topology: Step-down
- Datasheet: onsemi NCV2575D2T-5R4G
- Output Type: Fixed
- Input Voltage: 4.75V~40V
- Output Voltage: 5V
- Number of Outputs: 1
- Switching Frequency: 52kHz
- Output Current (Max): 1A
- Operating Temperature: -40°C~+125°C@(TJ)
- Synchronous Rectification: NO
- Package: D2PAK
- Manufacturer: onsemi
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Output Configuration: Positive
- Voltage - Input (Min): 4.75V
- Voltage - Input (Max): 40V
- Voltage - Output (Min/Fixed): 5V
- Voltage - Output (Max): -
- Current - Output: 1A
- Frequency - Switching: 52kHz
- Synchronous Rectifier: No
- Mounting Type: Surface Mount
- Package / Case: TO-263-6, D²Pak (5 Leads + Tab), TO-263BA
- Supplier Device Package: D2PAK-5
- Base Part Number: NCV2575
- detail: Buck Switching Regulator IC Positive Fixed 5V 1 Output 1A TO-263-6, D²Pak (5 Leads + Tab), TO-263BA
