NCP81610MNTXG دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت NCP81610MNTXG	دانلود دیتاشیت

NCP81610 30 pages

RoHS: true
Category: Power Supply Chip/AC-DC Controllers & Regulators
Topology: Step-down
Datasheet: onsemi NCP81610MNTXG
Supply Voltage: 2.8V~20V
Switching Frequency: 250kHz~1.2MHz
Operating Temperature: -10°C~+100°C@(TA)
Package: QFN-40-EP(5x5)
Manufacturer: onsemi
Series: -
Packaging: Tape & Reel (TR)
Part Status: Active
Output Type: PWM Signal
Function: Step-Down
Output Configuration: Positive
Number of Outputs: 8
Output Phases: 8
Voltage - Supply (Vcc/Vdd): 2.8V ~ 20V
Frequency - Switching: 250kHz ~ 1.2MHz
Duty Cycle (Max): -
Synchronous Rectifier: Yes
Clock Sync: No
Serial Interfaces: I²C, PSI
Control Features: Current Limit, Enable, Frequency Control, Power Good, Ramp, Soft Start, SPI
Package / Case: 40-VFQFN Exposed Pad
Supplier Device Package: 40-QFN (5x5)
Base Part Number: NCP81610
detail: Buck Regulator Positive Output Step-Down I²C, PSI DC-DC Controller IC 40-QFN (5x5)
