NCP1565MNTXG دیتاشیت

NCP1565MNTXG

مشخصات دیتاشیت

نام دیتاشیت NCP1565MNTXG
حجم فایل 93.865 کیلوبایت
نوع فایل pdf
تعداد صفحات 32

مشاهده دیتاشیت NCP1565MNTXG

دانلود دیتاشیت

سایر مستندات

NCP1565 31 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/AC-DC Controllers & Regulators
  • Topology: Forward
  • Datasheet: onsemi NCP1565MNTXG
  • Supply Voltage: 6.5V~20V
  • Switching Frequency: 100kHz~1.5MHz
  • Operating Temperature: -40°C~+125°C@(TJ)
  • Package: QFN-24-EP(4x4)
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Output Isolation: Isolated
  • Internal Switch(s): No
  • Voltage - Breakdown: -
  • Voltage - Start Up: 15V
  • Voltage - Supply (Vcc/Vdd): 6.5V ~ 20V
  • Duty Cycle: -
  • Frequency - Switching: 100kHz ~ 1.5MHz
  • Fault Protection: Current Limiting, Over Temperature, Short Circuit
  • Control Features: Frequency Control, Soft Start
  • Package / Case: 24-VFQFN Exposed Pad
  • Supplier Device Package: 24-QFN (4x4)
  • Mounting Type: Surface Mount
  • Base Part Number: NCP1565
  • detail: Converter Offline Forward Topology 100kHz ~ 1.5MHz 24-QFN (4x4)
