NTMFD5C462NLT1G دیتاشیت

NTMFD5C462NLT1G

مشخصات دیتاشیت

نام دیتاشیت NTMFD5C462NLT1G
حجم فایل 87.492 کیلوبایت
نوع فایل pdf
تعداد صفحات 7

مشاهده دیتاشیت NTMFD5C462NLT1G

دانلود دیتاشیت

سایر مستندات

NTMFD5C462NL 6 pages

مشخصات فنی

  • RoHS: true
  • Type: 2 N-Channel
  • Category: Triode/MOS Tube/Transistor/MOSFETs
  • Datasheet: onsemi NTMFD5C462NLT1G
  • Operating Temperature: -55°C~+175°C@(Tj)
  • Power Dissipation (Pd): 50W
  • Total Gate Charge (Qg@Vgs): 11nC@4.5V
  • Drain Source Voltage (Vdss): 40V
  • Input Capacitance (Ciss@Vds): 1.3nF@25V
  • Continuous Drain Current (Id): 84A
  • Gate Threshold Voltage (Vgs(th)@Id): 2.2V@40uA
  • Reverse Transfer Capacitance (Crss@Vds): 22pF@25V
  • Drain Source On Resistance (RDS(on)@Vgs,Id): 3.9mΩ@10V,10A
  • Package: DFN-8(5x6)
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • FET Type: -
  • FET Feature: -
  • Drain to Source Voltage (Vdss): -
  • Current - Continuous Drain (Id) @ 25°C: -
  • Rds On (Max) @ Id, Vgs: -
  • Vgs(th) (Max) @ Id: -
  • Gate Charge (Qg) (Max) @ Vgs: -
  • Input Capacitance (Ciss) (Max) @ Vds: -
  • Power - Max: -
  • Mounting Type: -
  • Package / Case: -
  • Supplier Device Package: -
  • Base Part Number: NTMFD5
  • detail: Mosfet Array
