دیتاشیت AX-SFEU-1-03-TX30
مشخصات دیتاشیت
| نام دیتاشیت | AX-SFEU, AX-SFEU-API |
|---|---|
| حجم فایل | 368.093 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 22 |
دانلود دیتاشیت AX-SFEU, AX-SFEU-API |
AX-SFEU, AX-SFEU-API Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Radio Frequency Chip/Antenna/RF Transceiver ICs
- Datasheet: onsemi AX-SFEU-1-03-TX30
- Interface: SPI,UART
- Applications: General-purpose ISM<1GHz
- Frequency Range: 868MHz
- Receive Current: 10mA
- Operating Voltage: 2.1V~3.6V
- Operating Temperature: -40°C~+85°C
- Current Of Transmitting: 19mA
- Package: QFN-40-EP(5x7)
- Manufacturer: onsemi
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Type: TxRx + MCU
- RF Family/Standard: General ISM < 1GHz
- Protocol: -
- Modulation: FSK, GFSK
- Frequency: 868MHz
- Data Rate (Max): 600bps
- Power - Output: 14dBm
- Sensitivity: -126dBm
- Memory Size: -
- Serial Interfaces: SPI, UART
- GPIO: 10
- Voltage - Supply: 2.1V ~ 3.6V
- Current - Receiving: 10mA
- Current - Transmitting: 19mA ~ 49mA
- Mounting Type: Surface Mount
- Package / Case: 40-VFQFN Exposed Pad
- Supplier Device Package: 40-QFN (7x5)
- Base Part Number: AX-SFEU
- detail: IC RF TxRx + MCU General ISM < 1GHz 868MHz 40-VFQFN Exposed Pad
