LV8740V-TLM-E دیتاشیت

LV8740V-TLM-E

مشخصات دیتاشیت

نام دیتاشیت LV8740V-TLM-E
حجم فایل 81.51 کیلوبایت
نوع فایل pdf
تعداد صفحات 25

مشاهده دیتاشیت LV8740V-TLM-E

دانلود دیتاشیت

سایر مستندات

LV8740V 25 pages

LV8740V Application Note 41 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Motor Driver ICs
  • Datasheet: onsemi LV8740V-TLM-E
  • Package: SSOP-44-EP-275mil
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Discontinued at Digi-Key
  • Motor Type - Stepper: Bipolar
  • Motor Type - AC, DC: Brushed DC
  • Function: Driver - Fully Integrated, Control and Power Stage
  • Output Configuration: Half Bridge (4)
  • Interface: Parallel
  • Technology: BiCDMOS
  • Step Resolution: 1, 1/2, 1/4
  • Applications: General Purpose
  • Current - Output: 2.5A
  • Voltage - Supply: 0V ~ 5.5V
  • Voltage - Load: 9V ~ 35V
  • Operating Temperature: -30°C ~ 85°C (TA)
  • Mounting Type: Surface Mount
  • Package / Case: 44-LSSOP (0.220", 5.60mm Width) Exposed Pad
  • Supplier Device Package: 44-SSOPJ
  • Base Part Number: LV874
  • detail: Bipolar Motor Driver BiCDMOS Parallel 44-SSOPJ
