دیتاشیت FDMF6840C-F013

FDMF6840C

مشخصات دیتاشیت

نام دیتاشیت FDMF6840C
حجم فایل 733.27 کیلوبایت
نوع فایل pdf
تعداد صفحات 19

دانلود دیتاشیت FDMF6840C

FDMF6840C Datasheet

مشخصات

  • RoHS: true
  • Category: Power Supply Chip/Gate Drive ICs
  • Load Type: MOSFET
  • Supply Voltage: 4.5V~5.5V
  • Driven Configuration: Half Bridge
  • Operating Temperature: -40°C~+150°C@(Tj)
  • Package: PQFN-40-EP(6x6)
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Output Configuration: Half Bridge
  • Applications: Synchronous Buck Converters
  • Interface: PWM
  • Technology: DrMOS
  • Rds On (Typ): 1Ohm LS + HS
  • Current - Output / Channel: 50A
  • Current - Peak Output: -
  • Voltage - Supply: 4.5V ~ 5.5V
  • Voltage - Load: 3V ~ 16V
  • Features: Bootstrap Circuit, Status Flag
  • Fault Protection: Over Temperature, Shoot-Through, UVLO
  • Mounting Type: Surface Mount
  • Package / Case: 40-TFQFN Exposed Pad
  • Supplier Device Package: 40-PQFN (6x6)
  • Base Part Number: FDMF6840
  • detail: Half Bridge Driver Synchronous Buck Converters DrMOS 40-PQFN (6x6)
