NCID9211R2 دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت NCID9211R2	دانلود دیتاشیت

RoHS: true
Category: Communication Interface Chip/UART/485/232/Digital Isolators
Data Rate: 50Mbps
Datasheet: onsemi NCID9211R2
Applications: I2C;SPI
Supply Voltage: 2.5V~5.5V
Forward Channel: 1
Reverse channel: 1
Number of Channels: 2
Isolation Technology: 电容隔离
Operating Temperature: -40°C~+150°C
Voltage Isolation or Not: Without voltage isolation
Package: SOP-16-300mil
Manufacturer: onsemi
Series: -
Packaging: Tape & Reel (TR)
Part Status: Active
Technology: Capacitive Coupling
Type: I²C, SPI
Isolated Power: No
Inputs - Side 1/Side 2: 1/1
Channel Type: Bidirectional
Voltage - Isolation: 5000Vrms
Common Mode Transient Immunity (Min): 100kV/µs
Propagation Delay tpLH / tpHL (Max): 25ns, 25ns
Pulse Width Distortion (Max): 10ns
Rise / Fall Time (Typ): 2.2ns, 3ns
Voltage - Supply: 2.5V ~ 5.5V
Mounting Type: Surface Mount
Package / Case: 16-SOIC (0.295", 7.50mm Width)
Supplier Device Package: 16-SOIC
detail: I²C, SPI Digital Isolator 5000Vrms 2 Channel 50Mbps 100kV/µs CMTI 16-SOIC (0.295", 7.50mm Width)
