دیتاشیت STK531U369A-E

STK531U369A-E

مشخصات دیتاشیت

نام دیتاشیت STK531U369A-E
حجم فایل 299.902 کیلوبایت
نوع فایل pdf
تعداد صفحات 13

دانلود دیتاشیت STK531U369A-E

STK531U369A-E Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Tube
  • Part Status: Not For New Designs
  • Output Configuration: Half Bridge (3)
  • Applications: AC Motors
  • Interface: Logic
  • Load Type: Inductive
  • Technology: IGBT
  • Rds On (Typ): -
  • Current - Output / Channel: 10A
  • Current - Peak Output: 20A
  • Voltage - Supply: 12.5V ~ 17.5V
  • Voltage - Load: 450V (Max)
  • Operating Temperature: -40°C ~ 150°C (TJ)
  • Features: Status Flag
  • Fault Protection: Current Limiting, UVLO
  • Mounting Type: Through Hole
  • Package / Case: 29-SSIP Module, 21 Leads, Formed Leads
  • Supplier Device Package: 29-SIP
  • Base Part Number: STK531
  • detail: Half Bridge (3) Driver AC Motors IGBT 29-SIP
