1SMA10CAT3 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
1SMA10CAT3
|
|
حجم فایل
|
55.723
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
6
|
مشخصات فنی
-
Manufacturer:
ON Semiconductor
-
Series:
Automotive, AEC-Q101
-
Packaging:
Cut Tape (CT)
-
Part Status:
Obsolete
-
Type:
Zener
-
Bidirectional Channels:
1
-
Voltage - Reverse Standoff (Typ):
10V
-
Voltage - Breakdown (Min):
11.1V
-
Voltage - Clamping (Max) @ Ipp:
17V
-
Current - Peak Pulse (10/1000µs):
23.5A
-
Power - Peak Pulse:
400W
-
Power Line Protection:
No
-
Applications:
Automotive
-
Capacitance @ Frequency:
580pF @ 1MHz
-
Operating Temperature:
-65°C ~ 150°C (TJ)
-
Mounting Type:
Surface Mount
-
Package / Case:
DO-214AC, SMA
-
Supplier Device Package:
SMA
-
Base Part Number:
1SMA10
-
detail:
17V Clamp 23.5A Ipp Tvs Diode Surface Mount SMA
