دیتاشیت MC34163P

مشخصات دیتاشیت

دانلود دیتاشیت MC34163, MC33163	MC34163, MC33163 Datasheet

Manufacturer: ON Semiconductor
Series: -
Packaging: Tube
Part Status: Obsolete
Function: Step-Up, Step-Down
Output Configuration: Positive or Negative
Topology: Buck, Boost
Output Type: Adjustable
Number of Outputs: 1
Voltage - Input (Min): 2.5V
Voltage - Input (Max): 40V
Voltage - Output (Min/Fixed): 1.25V
Voltage - Output (Max): 40V (Switch)
Current - Output: 3.4A (Switch)
Frequency - Switching: 50kHz
Synchronous Rectifier: No
Operating Temperature: 0°C ~ 70°C (TA)
Mounting Type: Through Hole
Package / Case: 16-DIP (0.300", 7.62mm)
Supplier Device Package: 16-DIP
Base Part Number: MC34163
detail: Buck, Boost Switching Regulator IC Positive or Negative Adjustable 1.25V 1 Output 3.4A (Switch) 16-DIP (0.300", 7.62mm)
