دیتاشیت NTD14N03R-001

NTD14N03R

مشخصات دیتاشیت

نام دیتاشیت NTD14N03R
حجم فایل 129.491 کیلوبایت
نوع فایل pdf
تعداد صفحات 6

دانلود دیتاشیت NTD14N03R

NTD14N03R Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Tube
  • Part Status: Obsolete
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 25V
  • Current - Continuous Drain (Id) @ 25°C: 2.5A (Ta)
  • Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
  • Rds On (Max) @ Id, Vgs: 95mOhm @ 5A, 10V
  • Vgs(th) (Max) @ Id: 2V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs: 1.8nC @ 5V
  • Vgs (Max): ±20V
  • Input Capacitance (Ciss) (Max) @ Vds: 115pF @ 20V
  • FET Feature: -
  • Power Dissipation (Max): 1.04W (Ta), 20.8W (Tc)
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Through Hole
  • Supplier Device Package: I-PAK
  • Package / Case: TO-251-3 Short Leads, IPak, TO-251AA
  • Base Part Number: NTD14
  • detail: N-Channel 25V 2.5A (Ta) 1.04W (Ta), 20.8W (Tc) Through Hole I-PAK
