NUP6101DMR2 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NUP6101DMR2
|
|
حجم فایل
|
146.258
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
4
|
مشخصات فنی
-
Manufacturer:
ON Semiconductor
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Obsolete
-
Type:
Zener
-
Unidirectional Channels:
6
-
Voltage - Reverse Standoff (Typ):
5V (Max)
-
Voltage - Breakdown (Min):
6V
-
Voltage - Clamping (Max) @ Ipp:
11V
-
Current - Peak Pulse (10/1000µs):
17A (8/20µs)
-
Power - Peak Pulse:
300W
-
Power Line Protection:
No
-
Applications:
General Purpose
-
Capacitance @ Frequency:
400pF @ 1MHz
-
Operating Temperature:
-55°C ~ 150°C (TJ)
-
Mounting Type:
Surface Mount
-
Package / Case:
8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
-
Supplier Device Package:
Micro8™
-
Base Part Number:
NUP6101
-
detail:
11V Clamp 17A (8/20µs) Ipp Tvs Diode Surface Mount Micro8™
