NTTD1P02R2 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NTTD1P02R2
|
|
حجم فایل
|
151.757
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
6
|
مشخصات فنی
-
Manufacturer:
ON Semiconductor
-
Series:
-
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Obsolete
-
FET Type:
2 P-Channel (Dual)
-
FET Feature:
Logic Level Gate
-
Drain to Source Voltage (Vdss):
20V
-
Current - Continuous Drain (Id) @ 25°C:
1.45A
-
Rds On (Max) @ Id, Vgs:
160mOhm @ 1.45A, 4.5V
-
Vgs(th) (Max) @ Id:
1.4V @ 250µA
-
Gate Charge (Qg) (Max) @ Vgs:
10nC @ 4.5V
-
Input Capacitance (Ciss) (Max) @ Vds:
265pF @ 16V
-
Power - Max:
500mW
-
Operating Temperature:
-55°C ~ 150°C (TJ)
-
Mounting Type:
Surface Mount
-
Package / Case:
8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
-
Supplier Device Package:
Micro8™
-
Base Part Number:
NTTD1
-
detail:
Mosfet Array 2 P-Channel (Dual) 20V 1.45A 500mW Surface Mount Micro8™
