NCP1086T-033 Datasheet

NCP1086

Datasheet specifications

Datasheet's name NCP1086
File size 188.522 KB
File type pdf
Number of pages 13

Download Datasheet NCP1086

Download Datasheet

Other documentations

No other documentation was found!

Technical specifications

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Tube
  • Part Status: Obsolete
  • Output Configuration: Positive
  • Output Type: Fixed
  • Number of Regulators: 1
  • Voltage - Input (Max): 7V
  • Voltage - Output (Min/Fixed): 3.3V
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): 1.4V @ 1.5A
  • Current - Output: 1.5A
  • Current - Quiescent (Iq): 10mA
  • PSRR: 80dB (120Hz)
  • Control Features: -
  • Protection Features: Over Current, Over Temperature
  • Operating Temperature: 0°C ~ 70°C
  • Mounting Type: Through Hole
  • Package / Case: TO-220-3
  • Supplier Device Package: TO-220AB
  • Base Part Number: NCP1086
  • detail: Linear Voltage Regulator IC 1 Output 1.5A TO-220AB
