NTQD6968NR2 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NTQD6968N
|
|
حجم فایل
|
88.843
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
7
|
مشخصات فنی
-
Manufacturer:
ON Semiconductor
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Obsolete
-
FET Type:
2 N-Channel (Dual)
-
FET Feature:
Logic Level Gate
-
Drain to Source Voltage (Vdss):
20V
-
Current - Continuous Drain (Id) @ 25°C:
6.2A
-
Rds On (Max) @ Id, Vgs:
22mOhm @ 7A, 4.5V
-
Vgs(th) (Max) @ Id:
1.2V @ 250µA
-
Gate Charge (Qg) (Max) @ Vgs:
17nC @ 4.5V
-
Input Capacitance (Ciss) (Max) @ Vds:
630pF @ 16V
-
Power - Max:
1.39W
-
Operating Temperature:
-55°C ~ 150°C (TJ)
-
Mounting Type:
Surface Mount
-
Package / Case:
8-TSSOP (0.173", 4.40mm Width)
-
Supplier Device Package:
8-TSSOP
-
Base Part Number:
NTQD69
-
detail:
Mosfet Array 2 N-Channel (Dual) 20V 6.2A 1.39W Surface Mount 8-TSSOP
