FDG6323L Datasheet
Datasheet specifications
| Datasheet's name | FDG6323L |
|---|---|
| File size | 152.207 KB |
| File type | |
| Number of pages | 4 |
Download Datasheet FDG6323L |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: ON Semiconductor
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Obsolete
- Switch Type: General Purpose
- Number of Outputs: 1
- Ratio - Input:Output: 1:1
- Output Configuration: High Side
- Output Type: P-Channel
- Interface: On/Off
- Voltage - Load: 2.5V ~ 8V
- Voltage - Supply (Vcc/Vdd): 1.5V ~ 8V
- Current - Output (Max): 600mA
- Rds On (Typ): 410mOhm
- Input Type: Non-Inverting
- Features: Slew Rate Controlled
- Fault Protection: -
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Surface Mount
- Supplier Device Package: SC-88 (SC-70-6)
- Package / Case: 6-TSSOP, SC-88, SOT-363
- Base Part Number: FDG6323
- detail: Power Switch/Driver 1:1 P-Channel 600mA SC-88 (SC-70-6)
