دیتاشیت SA17A

SA17A

مشخصات دیتاشیت

نام دیتاشیت SA17A
حجم فایل 863.258 کیلوبایت
نوع فایل pdf
تعداد صفحات 5

SA17A

دانلود دیتاشیت

سایر مستندات

SA5.0A 6 pages

SA12A 6 pages

SA17A 6 pages

SA17A 4 pages

مشخصات فنی

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/TVS
  • Datasheet: Littelfuse SA17A
  • Breakdown Voltage: 18.9V
  • Unidirectional Channels: 1
  • Maximum Clamping Voltage: 27.6V
  • Reverse Stand-Off Voltage (Vrwm): 17V
  • Peak Pulse Current (Ipp)@10/1000us: 18.5A
  • Peak Pulse Power Dissipation (Ppp)@10/1000us: 500W
  • Package: DO-15(DO-204AC)
  • Manufacturer: Littelfuse
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Obsolete
  • Type: Zener
  • Voltage - Reverse Standoff (Typ): 17V
  • Voltage - Breakdown (Min): 18.9V
  • Voltage - Clamping (Max) @ Ipp: 27.6V
  • Current - Peak Pulse (10/1000µs): 18.1A
  • Power - Peak Pulse: 500W
  • Power Line Protection: No
  • Applications: General Purpose
  • Capacitance @ Frequency: -
  • Operating Temperature: -
  • Mounting Type: Through Hole
  • Package / Case: DO-204AC, DO-15, Axial
  • Supplier Device Package: DO-15
  • Base Part Number: SA17
  • detail: 27.6V Clamp 18.1A Ipp Tvs Diode Through Hole DO-15
