دیتاشیت LM2574N-3.3G

مشخصات دیتاشیت

دانلود دیتاشیت LM2574, NCV2574 Series	LM2574, NCV2574 Series Datasheet

Manufacturer: ON Semiconductor
Series: -
Packaging: Tube
Part Status: Obsolete
Function: Step-Up, Step-Down, Step-Up/Step-Down
Output Configuration: Positive or Negative
Topology: Buck, Boost, Buck-Boost
Output Type: Fixed
Number of Outputs: 1
Voltage - Input (Min): 4.75V
Voltage - Input (Max): 40V
Voltage - Output (Min/Fixed): 3.3V
Voltage - Output (Max): -
Current - Output: 500mA
Frequency - Switching: 52kHz
Synchronous Rectifier: No
Operating Temperature: -40°C ~ 125°C (TJ)
Mounting Type: Through Hole
Package / Case: 8-DIP (0.300", 7.62mm)
Supplier Device Package: 8-PDIP
Base Part Number: LM2574
detail: Buck, Boost, Buck-Boost Switching Regulator IC Positive or Negative Fixed 3.3V 1 Output 500mA 8-DIP (0.300", 7.62mm)
