MBR10H100CT دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
MBR10H100CT
|
|
حجم فایل
|
84.232
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
3
|
مشخصات فنی
-
Manufacturer:
ON Semiconductor
-
Series:
SWITCHMODE™
-
Packaging:
Tube
-
Part Status:
Obsolete
-
Diode Configuration:
1 Pair Common Cathode
-
Diode Type:
Schottky
-
Voltage - DC Reverse (Vr) (Max):
100V
-
Current - Average Rectified (Io) (per Diode):
5A
-
Voltage - Forward (Vf) (Max) @ If:
730mV @ 5A
-
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
-
Current - Reverse Leakage @ Vr:
3.5µA @ 100V
-
Operating Temperature - Junction:
175°C (Max)
-
Mounting Type:
Through Hole
-
Package / Case:
TO-220-3
-
Supplier Device Package:
TO-220AB
-
Base Part Number:
MBR10H100
-
detail:
Diode Array 1 Pair Common Cathode Schottky 100V 5A Through Hole TO-220-3
