دیتاشیت BC337-16ZL1
مشخصات دیتاشیت
| نام دیتاشیت |
BC337-16ZL1
|
| حجم فایل |
84.671
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
6
|
مشخصات
-
Manufacturer:
ON Semiconductor
-
Series:
-
-
Packaging:
Tape & Box (TB)
-
Part Status:
Obsolete
-
Transistor Type:
NPN
-
Current - Collector (Ic) (Max):
800mA
-
Voltage - Collector Emitter Breakdown (Max):
45V
-
Vce Saturation (Max) @ Ib, Ic:
700mV @ 50mA, 500mA
-
Current - Collector Cutoff (Max):
100nA
-
DC Current Gain (hFE) (Min) @ Ic, Vce:
100 @ 100mA, 1V
-
Power - Max:
625mW
-
Frequency - Transition:
210MHz
-
Operating Temperature:
-55°C ~ 150°C (TJ)
-
Mounting Type:
Through Hole
-
Package / Case:
TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
-
Supplier Device Package:
TO-92-3
-
Base Part Number:
BC337
-
detail:
Bipolar (BJT) Transistor NPN 45V 800mA 210MHz 625mW Through Hole TO-92-3
