MSD1328-RT1G 数据手册
其他文档
未找到其他文档！
技术规格
- Manufacturer: ON Semiconductor
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Obsolete
- Transistor Type: NPN
- Current - Collector (Ic) (Max): 500mA
- Voltage - Collector Emitter Breakdown (Max): 20V
- Vce Saturation (Max) @ Ib, Ic: 400mV @ 20mA, 500mA
- Current - Collector Cutoff (Max): 100nA (ICBO)
- DC Current Gain (hFE) (Min) @ Ic, Vce: 200 @ 500mA, 2V
- Power - Max: 200mW
- Frequency - Transition: -
- Operating Temperature: 150°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: TO-236-3, SC-59, SOT-23-3
- Supplier Device Package: SC-59
- Base Part Number: MSD13
- detail: Bipolar (BJT) Transistor NPN 20V 500mA 200mW Surface Mount SC-59
