دیتاشیت MJE13003G

مشخصات دیتاشیت

دانلود دیتاشیت MJE13003	MJE13003 Datasheet

Manufacturer: ON Semiconductor
Series: SWITCHMODE™
Packaging: Bulk
Part Status: Obsolete
Transistor Type: NPN
Current - Collector (Ic) (Max): 1.5A
Voltage - Collector Emitter Breakdown (Max): 400V
Vce Saturation (Max) @ Ib, Ic: 3V @ 500mA, 1.5A
Current - Collector Cutoff (Max): -
DC Current Gain (hFE) (Min) @ Ic, Vce: 8 @ 500mA, 2V
Power - Max: 1.4W
Frequency - Transition: 10MHz
Operating Temperature: -65°C ~ 150°C (TJ)
Mounting Type: Through Hole
Package / Case: TO-225AA, TO-126-3
Supplier Device Package: TO-225AA
Base Part Number: MJE13
detail: Bipolar (BJT) Transistor NPN 400V 1.5A 10MHz 1.4W Through Hole TO-225AA
